BATHYDRONE
Aquatic Drone NANO
LIGHTWEIGHT AND MANEUVERABILITY
The compact surface aquatic drone for calm water bodies
The Bathydrone NANO is a surface aquatic drone specially designed for calm water bodies. With its performance suited for shallow waters and its lightweight, maneuverable design, the Bathydrone NANO is your ideal partner for quick and precise missions in various environments (port areas, inland waters, basins, etc.). Compatible with single and dual-frequency sonar systems, it integrates an RTK/PPK GNSS to provide centimeter-level data and allows for easy automatic mission programming directly from the shore.
Optimal maneuverability and easy deployment
Thanks to its minimal footprint and excellent maneuverability, the Bathydrone NANO is ideal for hard-to-reach environments. It also offers the advantages of an aquatic drone in calm waters while keeping costs under control.
Its clever, minimalist design coupled with its light weight allows for quick deployment, even by a single operator. It benefits from all the expertise developed for our other drone boats.
1 Opérator
Deployment in 5 minutes
Lightweight platform
Autonomy: 4 hours
Maximum speed: 1 m/s
Designed and assembled in France
Compatible with
Mono-frequency and Bi-frequency Sonar
The Bathydrone NANO is compatible with both single-frequency and dual-frequency sonar systems, offering flexibility for various types of inspections.
Single frequency:
500 kHz or 200 kHz
Dual frequency:
10 to 30 kHz in low frequency and
200 kHz in high frequency
+ Product
-
Compact, lightweight, and maneuverable platform
-
Ability to work in very shallow waters (20 cm)
-
Simple and quick deployment by a single operator
-
Automatic mission programming
-
Long-range remote control
Fields of application
-
Monofrequency, bifrequency bathymetry
-
Port areas, inland waters, lakes
Enjoy the Performance and Flexibility of the Bathydrone NANO
Contact us today to learn more about the Bathydrone NANO, its technical features, and its performance tailored to your specific needs.
Equip yourself with the compact and versatile aquatic drone for successful missions in calm water bodies.
Quick setup: training tailored to your professional needs.
Relatively intuitive, the setup requires less than a day's training for piloting.
This training, available remotely or in person, includes both theoretical and practical lessons on equipment knowledge, mission preparation and management, sonar data interpretation, and more.
As for the software, training can be completed in 1 to 2 days, depending on your needs and prior knowledge.
FEATURES
Dimensions:
L 85 cm × W 50 cm × H 30 cm
Weight:
20 kg with 1 battery
-
GPS + Sonar
Maximum speed:
1.3 m/sec
Minimum draft:
20 cm
Payload capacity:
3 kg
Recommended speed:
1 m/sec
EQUIPMENT & OPTIONS
-
Composite hull and RAL 1021 paint finish + varnish
-
2 brushless motors
-
Next-generation autopilot
-
Android remote control, range up to 0.5 km in open field
-
4 waterproof connectors
-
Current and voltage probe with display on the remote control
-
2 Lipo 20 Ah batteries and charger
-
1 waterproof camera with GoPro mount
-
Onboard PC (Windows)
