BATHYDRONE
Aquatic Drone VASCO
PERFORMANCE, SPEED, ROBUSTNESS, AND ACCURACY
The all-in-one Surface Drone!
VASCO is a surface drone compatible with a wide range of sensors (monofrequency, bifrequency, multibeam sonar, ADCP probe).
As bathymetry experts, we designed VASCO to meet all your underwater exploration and inspection needs. With customizable features and a design combining robustness and speed, VASCO will be your best ally for all types of missions.
VASCO integrates a GNSS RTK/PPK for centimeter-accurate data and allows you to easily program an automatic mission from the shore.
Your bathymetric surveys will never be the same.
Optimal stability in all environments
With enhanced stability and a speed of up to 3.6 m/s, VASCO moves with agility and precision in various environments, whether it’s inland waters, rivers, or coastal areas. Its shallow draft allows it to operate in very shallow water (20 cm).
With 8 hours of autonomy, this drone enables you to cover large exploration areas without compromising data accuracy.
1 Operator
Deployment in 5 minutes
Long range
Automatic mission
Autonomy
up to 8 hours
Maximum speed
3 m/s
Autonomy
up to 8 hours
EQUIPMENT & OPTIONS
-
Carbon fiber hull and paint + varnish finish
-
Anodized aluminum frame
-
2 brushless motors
-
Latest generation autopilot
-
Android remote control, range up to 2 km in line of sight
-
2 Lipo 22 Ah batteries and charger
-
Hot-swappable battery
-
Current and voltage probe with display on remote control
-
Embedded PC (Windows)
-
Electronic main switch with power-on indicator
-
Aluminum detachable transport cart
-
1 Waterproof camera with GoPro mount
-
Flashing light on the frame
-
Handles for transport
BathyDrone VASCO,
A custom configuration designed and manufactured in France.
As bathymetry experts, we offer a range of tools and sensors, carefully selected throughout our years of experience in bathymetric missions.
Extended sensor compatibility
A true chameleon, VASCO features a Central Multisensor Well that allows for the quick exchange and mounting of multiple instruments without tools. Fully customizable, this feature lets you select the options that suit your needs and expand your equipment over time.
-
Single frequency: 500 kHz or 200 kHz
-
Dual frequency: 10 to 30 kHz in low frequency and 200 kHz in high frequency
-
Multibeam sonar: 256 beams and inertial navigation system
-
Side scan sonar: Starfish Tritech
Embedded Measurement Instruments
Here is the translation:
A versatile gem, VASCO offers the possibility to integrate different additional equipment to cover a wide range of needs.
-
Winch for specific probes, remotely controlled (e.g., Swift SVP)
-
EXO3S multiparameter sensor with dedicated mapping software developed by us.
Hot-swappable batteries
Equipped with two 22 Ah rechargeable LiPo batteries, VASCO offers hot-swappable battery changes, allowing continuous exploration without resetting the sensors. A real advantage for long missions or in fast-moving waters.
Other options
Additional 6S 22 Ah battery
BathyLink: Communication box for GNSS and third-party total stations
Paint: Customizable color
Refrigerated surface water sampling enclosure (20 slots)
Simplification of mission programming and piloting
Quick Setup: Training tailored to your professional needs.
The new generation remote control integrates an Android system with a 12" touchscreen, ensuring visibility even in direct sunlight and a battery life of about 10 hours. It charges easily via USB-C.
The HYDROMAGIC acquisition software, implemented in the VASCO, enables the creation of automatic missions within a polygon, displays the compass, shows battery voltage, and more.
Relatively intuitive, the handling requires less than a day of training for piloting.
This training, available remotely or in person, includes theoretical and practical lessons on equipment knowledge, preparation and management of automatic missions, interpretation of sonar data, and more.
For the software side, learning can take 1 to 2 days, depending on your needs and prior knowledge.
Our partner ESCADRONE offers an e-learning training for a quick skills boost without the need to travel.
Find the Vasco at our authorized resellers:
